Thông tin chi tiết sản phẩm:
|
| Mẫu động cơ: | Cummins QSB6.7 | Công suất định mức: | 168kW/225HP |
|---|---|---|---|
| Trọng lượng vận hành: | 48000-52000kg | Dung tích gầu: | Xô đá 1,6m³ (Hạng nặng) |
| tối đa. độ sâu đào: | 7500mm | Max. tối đa. Digging Radius Bán kính đào: | 11500mm |
| Max. tối đa. digging height chiều cao đào: | 10500mm | Chiều dài bùng nổ: | 7000mm |
| Chiều dài cánh tay: | 3500mm | Khả năng tốt nghiệp: | 35° (70%) |
| Tốc độ xoay: | 10 vòng/phút | Tốc độ di chuyển: | 3,0-4,5 km/h |
| Áp suất hệ thống thủy lực: | 34,3mpa | Dung tích bình xăng: | 400L |
| Đầm xe: | Khung theo dõi gia cố hạng nặng | Lực lượng đào xô: | 280kN |
| Lực lượng đào cánh tay: | 220KN | ||
| Làm nổi bật: | 50T mining hydraulic crawler excavator,1.6m³ rock bucket excavator,heavy duty quarry excavator with reinforced boom |
||
The WORLD E250M Mining Grade Hydraulic Crawler Excavator is purpose-built for heavy-duty quarry and mining operations. Engineered with a reinforced boom, heavy-duty undercarriage, and a 1.6m³ rock bucket, this 50-ton excavator delivers exceptional digging force and durability in the toughest working conditions.
| Model | E250M |
| Engine Model | Cummins QSB6.7 |
| Rated Power | 168kW / 225HP @ 2000rpm |
| Operating Weight | 48000-52000kg |
| Bucket Capacity | 1.6m³ Rock Bucket (Heavy-Duty) |
| Max. Digging Depth | 7500mm |
| Max. Digging Radius | 11500mm |
| Max. Digging Height | 10500mm |
| Max. Dumping Height | 7300mm |
| Boom Length | 7000mm |
| Arm Length | 3500mm |
| Bucket Digging Force | 280kN |
| Arm Digging Force | 220kN |
| Swing Speed | 10rpm |
| Travel Speed | 3.0-4.5km/h |
| Gradeability | 35° (70%) |
| Hydraulic System Pressure | 34.3MPa |
| Fuel Tank Capacity | 400L |
The WORLD E250M excavator is shipped in nude packing with comprehensive anti-rust coating applied to all exposed metal surfaces. The machine is secured on a reinforced steel frame pallet suitable for ocean freight container or flat-rack transport. Standard delivery time is 30 working days after order confirmation.
Q1: What makes the E250M suitable for mining applications?
A1: The E250M features a reinforced boom and arm, heavy-duty undercarriage, 1.6m³ rock bucket, and 34.3MPa high-pressure hydraulic system delivering 280kN bucket digging force, specifically engineered for rock and mining conditions.
Q2: What engine does the E250M use?
A2: The E250M is powered by a Cummins QSB6.7 turbocharged diesel engine delivering 168kW (225HP), known for reliability and fuel efficiency in heavy-duty applications.
Q3: What is the minimum order quantity?
A3: The minimum order quantity is 1 unit. We support both single-unit purchases and bulk fleet orders.
Q4: What certifications does the E250M have?
A4: The E250M is CE and ISO 9001 certified, meeting international quality and safety standards.
Q5: Can the E250M be customized for specific mining conditions?
A5: Yes, we offer customization options including different bucket types, additional guarding packages, high-altitude configurations, and specialized track shoes for various ground conditions.
